P10-1100T data | ||
---|---|---|
Working width [m] | 11,00 | |
Transport width / height [m] | 3,00 / 2,70 | |
Number of rotors [pcs.] | 10 | |
Necessary hydraulic couplers | 1x double acting + 1x single acting | |
Working capacity [ha/h / ac/h] | 13,10 / 32 | |
Number of arms per rotor [pcs.] | 6 | |
Diameter of rotor [m] | 152 | |
RPM | 540 | |
Hitch type | D40 | |
Power demand [HP] | from 50 | |
PTO shaft | tractor-tedder: wide-angle with overruning clutch, built-in: with overload clutch | |
Tires | 18 x 8,5 - 8 x2 (central) / 16 x 6,5 - 8 x8 (side) / 340/55 - 16 x2 (transport) | |
Weight [kg] | 2600 |
