XDF
Discs mower - front
The XDF front mower combines reliability, high quality, and a modern design that adapts to current global trends. Hydropneumatic suspension, a wide ground-following range, and the PerfectCUT cutterbar are just a few of the XDF mower's advantages.
Share:
Print:
Do you want us to help you to search?
If you prefer us to find the most suitable machine for your needs, you just have to ask us. Together we will find YOUR MACHINE!!
Send inquiry
| Technical data | |||||
|---|---|---|---|---|---|
| Model | XDF 301 SH | XDF 351 SH | XDF 301 WH | XDF 351 WH | |
| Working Width | 3.00 | 3.50 | 3.00 | 3.5 | |
| Swath Width | ~1.00 - 1.40 | ~ 1.40 - 2.40 | ~1.00 - 1.40 | ~ 1.40 - 2.40 | |
| Transport Width | 3.00 | 3.50 | 3.00 | 3.5 | |
| Number of Discs | 7 | 8 | 7 | 8 | |
| Number of Knives | 14 | 16 | 14 | 16 | |
| Number of Hydraulic Connections Required | 1 x single-acting | 1 x single-acting | 1 x single-acting | 1 x single-acting | |
| PTO Speed | 1 | 1 | 1 | 1 | |
| Recommended Tractor Horsepower | from 80 | from 110 | from 80 | from 110 | |
| Weight | 1,470 / 3,240 | 1,570 / 3,460 | 1,450 / 3,200 | 1,57 | |
| Hitch Category | II | II | II | II | |
| PTO Shaft | Riding tractor: with integrated overrunning clutch: with overrunning clutch | Riding tractor: with integrated overrunning clutch: with overrunning clutch | Riding tractor: with integrated overrunning clutch: with overrunning clutch | Riding tractor: with integrated overrunning clutch: with overrunning clutch | |
| Working Capacity | ~3.50 / 8.70 | ~4.00 / 9.00 | ~3.50 / 8.70 | ~4.00 | |
| Single Rubber Windrower Guide | Adjustable, on conditioner | Adjustable, on conditioner | Adjustable, on conditioner | Adjustable, on conditioner | |
