Straps rake

Straps rake with three teeth per comb, suitable for small or medium power tractors. The adjustment of the working height can be carried out by means of levers placed on the pillars of the rear wheels. They are robust machines, very suitable for use on hills and mountains, also for swathing short grass.
T - Straps rake
+ Information
Machine data
Combs [ud]891011
Tines [ud]24273033
Working width [cm]140160180200
Maximun width [cm]160180200220
Speed [km/h]max.12max.12max.12max.12
Required power [HP]8 - 128 - 128 - 128 - 12
PTO [rpm]540540540540
Rotor chassis tires350-8"350-8"350-8"350-8"
Weight [kg]140150179205
