2080

Wheel loader

Weidemann wheel loaders increase productivity on all jobs. In addition to high functionality, a high level of comfort and the highest safety standards, they are very powerful and durable: Weidemann offers you the right solution for every task.
AUSAMA
AUSAMA
2080 - Wheel loader
Filter
+ Information
Engine data
StandardOptional
ManufacturerDeutzDeutz
ModelTD 2.9 L4 S5TCD 2.9 L4 S5
Engine output [kW / CV]45 / 6155,4 / 75
At maximum rpm [rpm]23002300
Cylinders [units]44
Displacement [cm3]29002900
CoolingWaterWater + Charge air
Exhaust standardStage VStage V
Exhaust after-treatmentDPF1 + DOC2DPF1 + DOC2

1 DPF: Diesel particulate filter
2 DOC: Diesel oxidation catalytic converter

Speed
Level 1 [km/h]7
Level 2 [km/h]20
Optional [km/h]28
Operating data
Operating weight [kg]4300
Tipping loads*
(According ISO 14397 - EN474-3)
With bucket straight [kg]3719
With bucket articulated [kg]3113
With pallet fork straight [kg]3170
With pallet fork articulated [kg]2662

* Horizontal loading frame

Hydraulic
KinematicsPZ
Lift cylinder [units]2
Tipping cylinder [units]1
Work hydraulics pressure [bar]210
Work hydraulics discharge volume [l/min]57,5
Driving hydraulics working pressure [bar]450
Steering system
SteeringHydraulic articulated pendulum steering
Articulation angle [º]45
Oscillating angle [º]± 12
Steering cylinder [units]1
Filling volumes
Fuel tank capacity [l]65
Hydraulic oil tank [l]50
Electrical system
Operating voltage [V]12
Battery isolator switch
Dimensions
Overall length [mm]5073
Total length without bucket [mm]4281
Center of axle up to the bucket pivot point [mm]675
Wheel base [mm]2045
Rear overhang [mm]1516
Height of low cabin [mm]2359
Height of high cabin [mm]2535
Seat height [mm]1429
Total working height [mm]3828
Max. height of the bucket pivot point [mm]3239
Overhead loading height [mm]2950
Dumping height [mm]2509
Scraping depth [mm]62
Total width [mm]1410
Lane width [mm]1113
Ground clearance [mm]270
Maximum radius [mm]3523
Radius on the outer edge [mm]3316
Inside radius [mm]1727
Rollback angle at max. lift height [º]52
Max. angle for bucket emptying [º]39
Rollback angle on the ground [º]45
